Road paver leveling lachine is a series of steel frame concrete roller pavers, the paving width (equals to road width) from 3m to 8m. Moving speed 4-9m/min, is a widely used and hot selling concrete road construction machinery.
Email: sale@piconcretemachine.com
Road paver leveling lachine is a series of steel frame concrete roller pavers, the paving width (equals to road width) from 3m to 8m.
Moving speed 4-9m/min, is a widely used and hot selling concrete road construction machinery.
Road paver leveling machine can be equipped with different powers, it can be equipped with gasoline or electric engine or Diesel Engine Generators, so no matter you are near or lack of electricity power supply, we have the models for your need.
To recommend you the proper truss screed length you need, you just need to tell us your concrete road width, and the engine type you prefer, then we will give you the best choice.
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Retail, Construction works
Technical Parameter of Concrete Paver Leveling Machine | ||||
Model | PI159 | PI168 | PI219A | PI219B |
Paving thickness | 300mm | 300mm | 150-300mm | 150-300mm |
PaviFng width | 0-6m | 3-6m | 3-8m | 3-8m |
Exciting frequency | 32HZ | 32HZ | 32HZ | 32HZ |
Exciting force | 5.5KN | 5.5KN | 5.5KN | 5.5KN |
Diameter of roller | 159mm | 168mm | 219mm | 219mm |
Walking speed | 10m/min | 8-10m/min | 9-12m/min | 9-12m/min |
Weight | 1600kg | 1000-1500kg | 1200kg | 1500KG |
Power Motor | 9.5kw-18.5kw | 4kw +4kw | 11KW | 13KW |
